Запчасти Komatsu PW75R-2 ЗАДН. МОСТ (WS) (/) ХОДОВАЯ

\0

22E-22-13000

REAR AXLE, ASSY.

1

226-22-11310

RING, NUT

2

226-22-11330

SCREW

3

21D-23-11280

BEARING

4

226-22-11550

DIFFERENTIAL

5

226-22-11360

CROWN WHEEL

6

226-22-11340

FRICTION WASHER

7

226-22-11390

PIN

8

226-22-11370

RING

9

226-22-11380

RING

10

226-22-11540

PLANET WHEEL

11

226-22-11410

FRICTION WASHER

12

226-22-11420

PLANETARY CARRIER

13

22E-23-12460

BEVEL GEAR PAIR, ASSY.

14

226-22-11351

BOLT

15

226-22-11280

BEARING

16

226-22-11440

SHIM, 0.100 mm

16

226-22-11430

SHIM, 0.150 mm

16

21D-23-11530

SHIM, 0.200 mm

16

21D-23-11550

SHIM, 0.300 mm

17

226-22-11450

SPACER

18

226-22-11460

SHIM, 0.100 mm

18

226-22-11470

SHIM, 0.150 mm

18

226-22-11480

SHIM, 0.200 mm

18

226-22-11490

SHIM, 0.400 mm

18

226-22-11510

SHIM, 0.500 mm

19

226-22-11520

SEAL

20

21D-23-11460

RING, NUT

21

21D-23-11180

RING, SNAP

22

21D-14-11540

BEARING

23

22E-22-12440

SEAL

24

22E-22-12470

BOLT

25

22E-22-12460

WASHER

26

22E-22-12480

BOLT

27

22E-22-12510

COVER
