Запчасти Komatsu PW75R-2 ЗАДН. МОСТ (WS) (/) ХОДОВАЯ

Схема запчастей Komatsu PW75R-2 - ЗАДН. МОСТ (WS) (/) ХОДОВАЯ
1
2
3
4
17
16
32
15
12
14
13
11
12
5
8
31
32
30
18
34
33
7
24
10
9
29
24
35
28
27
6
19
21
26
20
25
23
5
22

Артикул

Название

Примечание

Количество

\0

22E-22-13000

REAR AXLE, ASSY.

1

22E-22-11211

COVER

2

22E-22-11270

SCREW

3

226-22-11220

INLET SHAFT

4

22E-22-11230

BEARING

5

22E-22-11250

PIN

6

22E-22-11260

HOUSING

7

22E-22-11310

SPACER

8

226-22-11230

GEAR

9

22E-22-11320

SCREW

10

22E-22-11330

WASHER

11

22E-22-11340

PLATE

12

21D-14-11230

BEARING

13

226-22-11110

OUTLET SHAFT

14

22E-22-11360

CHANGE SELECTOR

15

22E-22-11370

GEAR

16

22E-22-11380

PLATE

17

22E-22-11390

SPACER

18

226-22-11140

CYLINDER

19

226-22-11170

PISTON

20

22E-22-11491

PLATE

21

21D-14-11180

SLIDE BLOCK

22

22E-22-11520

SELECTOR FORK

23

22E-22-11530

SELECTOR SHAFT

24

22E-22-11630

SEAL

25

22E-22-12410

O-RING

26

226-22-11180

O-RING

27

226-22-11160

O-RING

28

226-22-11150

PUSH-ROD

29

22E-22-11540

O-RING

30

22E-22-12420

BUSHING

31

22E-22-12390

SCREW

32

21D-23-11290

SPRING WASHER

33

226-22-11130

O-RING

34

226-22-11120

SCREW

35

21D-14-11720

PLUG

Выбрано товаров: 36
