Запчасти Komatsu PW75R-2 ПЕРЕДНИЙ МОСТ (WS) (/) ХОДОВАЯ

\0

22E-23-13000

FRONT AXLE, ASSY.

1

226-22-11721

HOUSING

2

226-22-11722

HOUSING

3

226-22-11670

PIN, ASSY.

4

PIN

5

22E-23-11550

FITTING

6

22E-23-11990

PLUG

7

226-22-11350

BOLT

8

226-22-11930

SHIM, 0.150 mm

8

226-22-11940

SHIM, 0.200 mm

8

226-22-11950

SHIM, 0.500 mm

9

226-22-11651

BUSHING

10

226-22-11690

SEAL

11

226-22-11660

COVER

12

226-22-11680

PIN, ASSY.

13

PIN

14

22E-23-11550

FITTING

15

226-22-11690

SEAL

16

226-22-11710

ARTICULATION

17

226-22-11881

CHECK BOLT

18

226-22-11890

NUT

19

226-22-11750

SEAL

20

226-22-11760

BEARING

21

21D-23-12641

WHEEL HUB

22

21D-23-11820

STEERING COLUMN

23

21D-23-11110

O-RING

24

22E-23-12510

PLANET GEAR CARRIER, ASSY

25

226-22-11780

GEAR, RING

26

226-22-11870

RING

27

226-22-11790

SUPPORT

28

226-22-11820

PLANET WHEEL

29

226-22-11830

BEARING

30

226-22-11810

RING

31

21D-23-12651

PLANET GEAR CARRIER

32

226-22-11920

PLATE

33

226-22-11850

STUD

34

226-22-11860

NUT

35

21D-23-12111

SCREW

36

21D-23-11970

PLUG

37

21D-23-11960

WASHER

38

21D-23-11850

NUT
