Запчасти Komatsu PW75R-2 СТАРТЕР ДВИГАТЕЛЬ

Схема запчастей Komatsu PW75R-2 - СТАРТЕР ДВИГАТЕЛЬ
22
1
19
17
20
21
16
3
12
4
14
11
5
10
18
9
15
13
6
8
7
2
A

Артикул

Название

Примечание

Количество

\0

22E-01-11000

MOTOR, ASSY.

1

YM129900-77010

STARTER MOTOR

2

YM129900-77400

ROTOR,ASSY.

3

YM129900-77440

COIL ASSY.,FIELD

4

YM129900-77450

BRUSH (+)

5

YM171008-77450

SCREW

6

YM129900-77460

COVER, REAR

7

YM129900-77480

HOLDER BRUSH, ASSY.

8

YM129900-77500

BRUSH (--)

9

YM129900-77510

PINION, ASSY.

10

YM129900-77520

CLUTCH, ASSY.

11

YM171008-77730

BEARING

12

YM171008-77740

BEARING

13

YM129900-77540

SHAFT

14

YM129900-77550

SPACER

15

YM129900-77610

RETAINER

16

YM129900-77590

SWITCH, MAGNETIC

17

YM129900-77620

LEVEL SET

18

YM129900-77640

BOLT

19

YM129900-77650

PAN ASSY., DUST

20

YM129900-77710

HOUSING

21

YM171008-77750

COVER

22

YM26116-120302

BOLT

Выбрано товаров: 23
