Запчасти Komatsu PW75R-2 ПЕРЕДНИЙ МОСТ (WS) (/) ХОДОВАЯ

\0

22E-23-11000

FRONT AXLE, ASSY.

1

22E-23-11750

HOUSING

2

22E-23-11760

HOUSING

3

22E-23-11190

PIN

4

22E-23-11550

FITTING

5

22E-23-11560

SCREW

6

22E-23-11570

WASHER

7

22E-23-11580

SHIM, 0.150 mm

7

22E-23-11590

SHIM, 0.200 mm

7

22E-23-11610

SHIM, 0.500 mm

8

22E-23-11620

SNAP RING

9

22E-23-11630

BEARING

10

22E-23-11730

NUT

10

22E-23-11730

NUT

11

22E-23-12330

SCREW

12

22E-23-11770

SNAP RING

13

22E-23-11780

BEARING

14

22E-23-11880

HUB

15

21D-23-11820

STEERING COLUMN

16

21D-23-11850

NUT

17

21D-23-11840

O-RING

18

22E-23-11790

CIRCLIP

19

22E-23-11810

SUPPORT

20

22E-23-11820

GEAR, RING

21

21D-23-11930

RING, SNAP

22

22E-23-11910

SLEEVE

23

22E-23-11870

BOLT

24

21D-23-12140

SHIM

25

22E-23-11850

PLANET WHEEL

26

21D-23-12120

BEARING

27

21D-23-12370

SPACER

28

21D-23-11950

CASE

29

21D-23-12110

SCREW

30

21D-23-11960

WASHER

31

21D-23-11970

PLUG

32

21D-23-11990

PIN

33

21D-23-11980

O-RING

34

22E-23-12440

SPACER
