Запчасти Komatsu PW75R-2 ЗАДН. МОСТ (WS) (/) ХОДОВАЯ

\0

22E-22-11000

REAR AXLE, ASSY.

1

22E-23-11350

RING, NUT

2

22E-23-11220

PLATE

3

22E-23-11210

SCREW

4

21D-23-12570

BOLT

5

21D-23-11290

SPRING WASHER

6

22E-23-11230

PLANETARY CARRIER

7

22E-23-11240

BEVEL GEAR, ASSY.

8

22E-23-11250

PIN

9

22E-22-11730

PLANET WHEEL

10

22E-23-11270

WASHER

11

22E-23-11280

PEG

12

22E-23-11290

PIN

13

22E-23-11310

CROWN WHEEL

14

22E-23-11320

WASHER

15

22E-23-11330

FLANGE

16

22E-23-11340

BEARING

17

22E-23-11360

SCREW

18

22E-22-11740

SPIDER

19

22E-23-11370

BEARING

20

22E-22-11770

SNAP RING

21

22E-22-11820

SHIM, 0.100 mm

21

22E-22-11830

SHIM, 0.150 mm

21

22E-22-11840

SHIM, 0.250 mm

21

22E-22-11850

SHIM, 0.500 mm

22

22E-22-11750

SPACER

23

22E-22-11810

RING

24

22E-23-11430

SHIM, 0.100 mm

24

22E-23-11420

SHIM, 0.150 mm

24

22E-23-11390

SHIM, 0.200 mm

24

22E-23-11410

SHIM, 0.300 mm

25

22E-22-11790

FLANGE

26

22E-22-11270

SCREW

26

22E-22-11780

BOLT

27

22E-22-11760

RING, NUT

28

21D-14-11540

BEARING
