Запчасти Komatsu PW75R-2 ЗАДН. МОСТ (WS) (/) ХОДОВАЯ

\0

22E-22-11000

REAR AXLE, ASSY.

1

22E-22-11110

O-RING

2

22E-22-11120

PLUG

3

22E-22-11130

COVER

4

22E-22-11140

GASKET

5

22E-22-11150

SHIM, 0.100 mm

5

22E-22-11180

SHIM, 0.150 mm

5

22E-22-11190

SHIM, 0.200 mm

5

22E-22-11160

SHIM, 0.300 mm

5

22E-22-11170

SHIM, 0.400 mm

6

21D-14-11540

BEARING

7

22E-22-11650

PLATE

8

21D-23-11210

PLUG

9

21D-14-11330

SENSOR, REVOLUTION

10

21D-14-11270

PROTECTION

11

21D-14-11280

SWITCH

12

21D-14-11290

WASHER

13

22E-22-11580

GASKET

14

22E-22-11410

BOLT

15

21D-14-11710

SPRING

16

21D-14-11680

BALL

17

21D-23-12350

PLUG

18

21D-14-11460

BEARING

19

22E-22-11620

GASKET

20

22E-22-11610

COVER

21

22E-22-11590

FLANGE

22

22E-22-11640

RING

23

22E-23-11490

NUT

24

22E-22-11270

SCREW
