Запчасти Komatsu PW75R-2 ЗАДН. МОСТ (WS) (/7) ХОДОВАЯ

\0

22E-22-11010

REAR AXLE, ASSY.

1

22E-23-11210

SCREW

2

22E-23-11220

PLATE

3

21D-23-12570

BOLT

4

21D-23-11290

SPRING WASHER

5

22E-23-11230

PLANETARY CARRIER

6

22E-23-11241

BEVEL GEAR, ASSY.

7

22E-23-11250

PIN

8

22E-23-11260

PLANET WHEEL

9

22E-23-11270

WASHER

10

22E-23-11280

PEG

11

22E-23-11290

PIN

12

22E-23-11310

CROWN WHEEL

13

22E-23-11320

WASHER

14

22E-23-11330

FLANGE

15

22E-23-11340

BEARING

16

22E-23-11350

RING, NUT

17

22E-23-11360

SCREW

18

22E-23-11510

CROSS JOURNAL

19

22E-23-11370

BEARING

20

22E-23-11440

SHIM, 0.100 mm

20

22E-23-11450

SHIM, 0.150 mm

20

22E-23-11460

SHIM, 0.200 mm

21

22E-22-11770

SNAP RING

22

22E-22-11750

SPACER

23

22E-23-11430

SHIM, 0.100 mm

23

22E-23-11420

SHIM, 0.150 mm

23

22E-23-11390

SHIM, 0.200 mm

23

22E-23-11410

SHIM, 0.300 mm

24

22E-22-11760

RING, NUT

25

21D-14-11540

BEARING

26

22E-22-11270

SCREW

27

22E-22-12280

STUD

28

22E-23-11530

NUT
