Запчасти Komatsu PW75R-2 ТОПЛИВН. ЛИНИЯ ДВИГАТЕЛЬ

\0

22E-01-11000

MOTOR, ASSY.

1

YM22190-140002

GASKET

2

YM119000-55600

FILTER

3

YM129470-55610

BODY

4

YM23414-080000

GASKET

5

YM26106-100252

BOLT

6

YM101304-59020

UNION

7

YM124766-59050

CLAMP

8

YM121855-59111

CLAMP

9

YM103854-59191

BOLT

11

YM124060-59380

PLUG

12

YM22190-060002

SPRING WASHER

13

YM129335-59090

PIPE L=500

14

YM129335-59090

PIPE L=500

15

YM119006-59910

JOINT

16

YM26106-080102

PLUG

17

YM121855-59880

JOINT

18

YM22190-120002

GASKET

19

YM23857-060000

BOLT

20

YM121855-59880

JOINT

21

YM124766-59050

CLAMP

22

YM124066-59100

CLAMP

23

YM129495-59300

BOLT

24

YM105025-59560

PIPE

25

YM129980-59530

JOINT

26

YM121250-59550

PIPE

27

YM105225-59120

PIPE

28

YM129150-59580

PLUG

29

YM128300-59910

VALVE

35

YM22190-140002

GASKET

36

YM121850-55800

WATER SEPARATOR

37

YM104200-55321

VALVE, TAPER

38

YM104200-55330

SPRING

39

YM104200-55341

HANDLE, COCK

40

YM121254-55510

TANK

41

YM102103-55520

O-RING

42

YM110250-55610

RING, NUT

44

YM121850-55710

FILTER

45

YM121257-55720

SPRING

46

YM121257-55731

FLOAT

47

YM101720-55750

PLUG

48

YM104200-55750

SCREW

49

YM23418-060000

GASKET

50

YM24311-240100

O-RING
