Запчасти Komatsu PW75-1 ЗАДН. МОСТ (WS) (/7) ХОДОВАЯ

Схема запчастей Komatsu PW75-1 - ЗАДН. МОСТ (WS) (/7) ХОДОВАЯ
2
1
34
3
a
a
4
15
14
17
16
5
18
12
11
12
13
37
41
40
43
19
34
8
7
10
36
9
23
24
6
42
27
37
2
38
29
28
39
33
40
21
36
22
29
19
20
35
32
31
30
25
23
24
28
27
26
5

Артикул

Название

Примечание

Количество

\0

22E-22-11010

REAR AXLE, ASSY.

1

22E-22-11210

COVER

1

22E-22-11211

COVER

2

22E-22-11270

SCREW

3

22E-22-11220

INLET SHAFT

4

22E-22-11230

BEARING

5

22E-22-11250

PIN

6

22E-22-11260

HOUSING

7

22E-22-11310

SPACER

8

22E-22-11240

GEAR

9

22E-22-11320

SCREW

10

22E-22-11330

WASHER

11

22E-22-11340

PLATE

12

21D-14-11230

BEARING

13

22E-22-11350

OUTLET SHAFT

14

22E-22-11360

CHANGE SELECTOR

15

22E-22-11370

GEAR

16

22E-22-11380

PLATE

17

22E-22-11390

SPACER

18

21D-23-11210

PLUG

19

22E-22-11460

CYLINDER

19

22E-22-11461

CYLINDER

20

21D-14-11730

PISTON

21

22E-22-11470

GASKET

22

22E-22-11480

O-RING

23

21D-14-11770

PISTON

24

22E-22-11490

PLATE

24

22E-22-11491

PLATE

25

21D-14-11180

SLIDE BLOCK

26

22E-22-11520

SELECTOR FORK

27

22E-22-11530

SELECTOR SHAFT

28

22E-22-11630

RING, SNAP

29

22E-22-11540

O-RING

30

22E-22-11550

O-RING

31

21D-14-11750

PISTON

32

22E-22-11560

RING

33

21D-14-11740

SHIM

34

22E-22-11510

O-RING

35

21D-23-11220

DOWEL

36

22E-22-11570

SELECTOR SHAFT

37

21D-14-11820

RING

38

22E-22-11430

RING

39

22E-22-11440

RING

40

22E-22-11450

RING, SNAP

41

22E-22-11270

SCREW

41

22E-22-12390

SCREW

42

22E-22-12410

O-RING

43

22E-22-12420

BUSHING

Выбрано товаров: 48
