Запчасти Komatsu PW75-1 ГИДРОЛИНИЯ (ЗАДН. ОПОРА) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

1

21D-09-51220

UNION

2

21D-09-69910

O-RING

3

21D-09-55630

ELBOW

4

21D-09-51230

UNION

5

21D-09-69970

O-RING

6

22E-09-12610

HOSE

7

21D-09-93490

HOSE

8

22E-62-11960

PIPE

9

22E-62-11950

PIPE

10

22E-62-11940

PIPE

11

21D-09-68220

CLAMP

12

01016-50830

BOLT

13

01643-30823

WASHER

14

21D-09-57450

UNION

15

22E-62-11970

PIPE

16

22E-62-11980

PIPE

17

21D-09-68180

HOSE-CLAMP

18

01010-50630

BOLT

19

01643-30623

WASHER

20

21D-09-57280

ELBOW

21

21D-09-51220

UNION

22

21D-09-69910

O-RING

23

21D-60-17200

VALVE, ASSY.

24

21D-60-17250

KIT, GASKET

25

21D-09-51660

ELBOW

26

21D-09-69910

O-RING

27

21D-09-53120

FLANGE

28

01252-40830

SCREW

29

21D-09-73690

SPRING WASHER

30

21D-09-69110

O-RING

31

21D-62-15310

UNION

32

21D-09-69910

O-RING

33

21D-62-15290

UNION

34

21D-09-69910

O-RING

35

21D-62-13640

PIPE

36

21D-09-55650

ELBOW

37

21D-62-11790

FLANGE

38

21D-09-95420

HOSE

39

21D-09-95410

HOSE
