Запчасти Komatsu PW75-1 ТОПЛ. НАСОС ДВИГАТЕЛЬ

Схема запчастей Komatsu PW75-1 - ТОПЛ. НАСОС ДВИГАТЕЛЬ
4
27
19
21
1
22
20
99
17
18
100
6
16
7
94
15
5
9
8
61
98
11
10
96
60
97
101
93
3
95
92
66
83
67
71
13
62
14
63
64
65
2
70
102
72
58
68
69
57
59
28
23
24
26
25
12

Артикул

Название

Примечание

Количество

\0

22E-01-11000

ENGINE, ASSY.

1

YM129980-51000

PUMP, ASSY.

1

REGULATOR, ASSY.

2

YMX0265101340

GASKET

3

YMX1310641621

HOUSING

4

YMX0290406020

STUD

5

YMX1340260000

PLUG

6

YMX1310022000

PLUG

7

YMX1310022000

PLUG

8

YMX1310286220

COVER

9

YMX1310111900

GASKET

10

YMX1310171000

SCREW

11

YMX0293406020

GASKET

12

YMX1310341401

PLUG

13

YMX1392060400

NUT

14

YMX0296331010

O-RING

15

YMX1311523420

PLUNGER

16

YMX1311607920

VALVE DELIVERY

17

YMX1311123500

SPRING

18

YMX1311151600

GASKET

19

YMX1311167600

GUARD, DELIVERY VALVE

20

YMX1311172300

STOPPER

21

YMX1311220520

PLATE

22

YMX0296320030

O-RING

23

YMX1312000220

TAPPET

24

YMX1312030200

PIN

25

YMX1312041000

WHEEL

26

YMX1312050500

BUSHING

27

YMX1312060200

GUIDE

28

YMX0293110020

SHIM, 0.300 mm

28

YMX0293110030

SHIM, 0.400 mm

28

YMX0293110040

SHIM, 0.500 mm

28

YMX0293110050

SHIM, 0.600 mm

28

YMX0293110060

SHIM, 0.700 mm

28

YMX0293110070

SHIM, 0.800 mm

28

YMX0293110080

SHIM, 0.900 mm

28

YMX0293110090

SHIM, 1.000 mm

28

YMX0293110110

SHIM, 1.100 mm

28

YMX0293110120

SHIM, 1.200 mm

28

YMX0293110130

SHIM, 1.300 mm

28

YMX0293110140

SHIM, 1.400 mm

28

YMX0293110270

SHIM, 0.550 mm

28

YMX0293110280

SHIM, 0.650 mm

28

YMX0293110290

SHIM, 0.750 mm

28

YMX0293110310

SHIM, 0.850 mm

28

YMX0293110320

SHIM, 0.950 mm

28

YMX0293110330

SHIM, 1.050 mm

28

YMX0293110340

SHIM, 1.150 mm

28

YMX0293110350

SHIM, 1.250 mm

28

YMX0293110490

SHIM, 1.500 mm

28

YMX0293110500

SHIM, 1.600 mm

28

YMX0293110580

SHIM, 0.200 mm

28

YMX0293110590

SHIM, 0.250 mm

28

YMX0293110600

SHIM, 0.350 mm

28

YMX0293110610

SHIM, 0.450 mm

28

YMX0293110620

SHIM, 1.350 mm

28

YMX0293110630

SHIM, 1.450 mm

28

YMX0293110710

SHIM, 1.550 mm

57

YMX1312152500

SPRING

58

YMX1312160100

SEAT

59

YMX1312170200

SEAT

60

YMX1312540600

RACK

61

YMX1312260300

SCREW

62

YMX1312400100

PINION

63

YMX1312410100

SLEEVE

64

YMX1312420100

SCREW

65

YMX1313612700

CAMSHAFT

66

YMX0166402030

BEARING

67

YMX0282020020

BEARING

68

YMX0166302030

BEARING

69

YMX0282017020

BEARING

70

YMX1313020300

SPACER

71

YMX1313021000

SPACER

72

YMX0293117010

SHIM, 0.100 mm

72

YMX0293117020

SHIM, 0.120 mm

72

YMX0293117030

SHIM, 0.140 mm

72

YMX0293117040

SHIM

72

YMX0293117050

SHIM

72

YMX0293117060

SHIM

72

YMX0293117070

SHIM

72

YMX0293117090

SHIM

72

YMX0293117210

SHIM

72

YMX0293117220

SHIM

72

YMX1394170000

SHIM, 2.400 mm

83

YMX0293120220

SHIM

83

YMX0293120230

SHIM

83

YMX0293120240

SHIM

83

YMX0293120250

SHIM

83

YMX0293120260

SHIM

83

YMX0293120270

SHIM

83

YMX0293120290

SHIM

83

YMX0293120300

SHIM

83

YMX1394200400

SHIM, 0.700 mm

92

YMX0296220190

GASKET

93

YMX1313301800

COVER

94

YMX0200062040

BOLT

95

YMX1313211900

GASKET

96

YMX0131214140

NUT

97

YMX0293214010

SPRING WASHER

98

YMX0294704030

KEY

99

YMX0297314680

BOLT

100

YMX0265141840

GASKET

101

YMX0296375020

O-RING

102

YMX0297310120

BOLT

Выбрано товаров: 104
