Запчасти Komatsu PW400MH-6 FIG. A-BF СТАРТЕР - KW ДВИГАТЕЛЬ

|$0

600-813-9311

STARTER MOTOR ASSEMBLY (11KW)

1

KD0-23100-0430

ARMATURE ASSEMBLY

2

KD1-0456-62057

BEARING, BALL

3

KD1-0456-62017

BEARING, BALL

4

KD0-23200-0670

YOKE ASSEMBLY

5

KD0-23310-1670

FRONT BRACKET ASSEMBLY

6

KD1-23351-0080

METAL

7

KD1-23761-0010

COVER

8

KD0-23120-0180

SHAFT ASSEMBLY

9

KD0-09201-0850

BEARING, BALL

10

KD1-23181-0020

STOPPER, PINION

11

KD1-23914-0020

RING, CLIP

12

KD0-23500-0970

CLUTCH ASSEMBLY

13

KD0-23600-0410

CENTER BRACKET

14

KD0-23611-1100

BRACKET, CENTER

15

KD0-23320-0290

SHIFT LEVER ASSEMBLY

16

KD0-47100-4650

MAGNETIC SWITCH

17

KD0-23710-0220

BRACKET

18

KD0-23750-0150

BRUSH HOLDER

19

KD1-23913-0040

SPRING, BRUSH

20

KD1-23740-0351

BRUSH ASSEMBLY

21

KD0-09001-4380

BOLT

22

KD0-25000-8281

SWITCH ASSEMBLY, SAFETY

23

KD1-09211-0981

O-RING

24

KD1-09210-1060

SEAL, OIL

25

KD1-23951-0051

PACKING

26

KD1-09211-1120

O-RING

27

KD1-0345-08001

WASHER, SEAL

28

KD1-09211-0081

O-RING

29

KD1-09211-0081

O-RING

30

KD1-09252-0420

CAP

31

KD1-09252-0211

CAP

32

KD1-23921-0130

WASHER

33

KD1-23921-0140

WASHER

34

KD1-23941-0040

WASHER

35

KD0-09057-0110

WASHER

36

KD0-09057-0190

WASHER
