Запчасти Komatsu PW400MH-6 FIG. N-A МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

208-26-63170

CASE

2

06000-23124

BEARING

3

06000-22326

BEARING

4

208-26-52262

COVER

5

01010-81040

BOLT

6

01643-31032

WASHER

7

208-62-61290

SEAL

8

208-26-52242

SHAFT

9

208-26-61151

COUPLING

10

208-26-52230

PLATE

11

205-32-51211

BOLT, SHOE

12

207-27-63170

CARRIER

13

208-26-63140

GEAR, 2P

14

207-27-63210

BEARING, 2P

15

20Y-27-21250

WASHER

16

207-27-63230

PIN

17

20Y-27-21330

PIN

18

207-27-63150

GEAR

19

207-27-63250

WASHER

20

208-26-63130

GEAR

21

20Y-27-13310

WASHER

22

207-26-61180

GUIDE

23

208-26-63150

CARRIER, 1C

24

208-26-63120

GEAR

25

20Y-27-22210

BEARING

26

20Y-27-21240

WASHER

27

20Y-27-21220

PIN

28

20Y-27-21280

PIN

29

208-26-63110

GEAR

30

20Y-27-11250

SPACER

31

208-26-63160

COVER

32

01011-61880

BOLT

33

01643-31845

WASHER

34

07042-00312

PLUG

35

07730-40004

VALVE

36

207-26-31220

TUBE

37

07281-00197

CLAMP

38

07000-15335

O-RING

39

01010-82485

BOLT

40

01643-32460

WASHER

41

208-26-62180

GAUGE

42

208-26-62190

FILLER
