Запчасти Komatsu PW400MH-6 FIG. H8-AB ОСНОВН. ЛИНИЯ PPC - КЛАПАН ЛИНИИ PPC ГИДРАВЛИКА

Схема запчастей Komatsu PW400MH-6 - FIG. H8-AB ОСНОВН. ЛИНИЯ PPC - КЛАПАН ЛИНИИ PPC ГИДРАВЛИКА
6
10
3
9
12
7
5
16
15
14
18
6
1
27
2
10
14
11
4
13
8
4
3
17
9
12
30
23
32
29
11
22
8
21
25
28
24
2
20
28
30
26
21
1
33
15
22
16
29
5
27
23
19
18
17
20
32
26
19
31
3
24
25
7

Артикул

Название

Примечание

Количество

1

203-62-52260

HOSE, 1300MM

2

203-62-52530

HOSE, 800MM

3

207-62-63421

HOSE, 920MM

4

207-62-63630

HOSE, 470MM

5

20Y-62-22661

HOSE, 470MM

6

20Y-62-22671

HOSE, 355MM

7

20Y-62-22681

HOSE, 520MM

8

20Y-62-22691

HOSE, 315MM

9

20Y-62-22721

HOSE, 535MM

10

20Y-62-22790

BAND, RED

11

20Y-62-22810

BAND, YELLOW

12

20Y-62-22820

BAND, BLUE

13

20Y-62-22830

BAND, WHITE

14

20Y-62-22840

BAND, BLACK

15

20Y-62-22850

BAND, GREEN

16

20Y-62-22860

BAND, BROWN

17

08034-00536

BAND

18

207-62-63640

HOSE, 620MM

19

20Y-62-22721

HOSE, 535MM

20

20Y-62-22741

HOSE

21

20Y-62-22761

HOSE, 840MM

22

20Y-62-23861

HOSE, 1050MM

23

20Y-62-22781

HOSE, 650MM

24

20Y-62-23831

HOSE, 800MM

25

20Y-62-22840

BAND, BLACK

26

20Y-62-22790

BAND, RED

27

20Y-62-22820

BAND, BLUE

28

20Y-62-22830

BAND, WHITE

29

20Y-62-22850

BAND, GREEN

30

20Y-62-22860

BAND, BROWN

31

08034-00536

BAND

32

20Y-62-22681

HOSE, 520MM

33

08034-00536

BAND

Выбрано товаров: 33
