Запчасти Komatsu PW400MH-6 FIG. H-8A ОСНОВН. НАСОС - ЗАДН. CRADLE ГИДРАВЛИКА

|$2

708-2H-04160

CRADLE ASSEMBLY

1

NSS

CRADLE

2

NSS

CAM, ROCKER

3

04020-01434

PIN

4

07000-B1009

O-RING

5

706-75-40340

BOLT

6

708-2H-24310

PISTON

7

708-2H-24220

ROD

8

04020-00514

PIN

9

708-2H-25870

CAM

10

01010-80825

BOLT

11

01643-30823

WASHER

12

708-2H-24260

STOPPER

13

07000-B3032

O-RING

14

07001-03032

RING

15

708-2H-24320

SCREW

16

01643-32460

WASHER

17

01583-52414

NUT

18

708-2H-24270

SCREW

19

708-1W-28910

O-RING

20

708-2H-24140

SPRING

21

708-2H-24130

PLUG

22

708-2L-24620

O-RING

23

708-2H-22140

COUPLING

24

708-2H-12420

RING

25

708-2H-21860

BEARING

26

708-2H-21820

GEAR

27

708-2H-21850

BUSHING

28

708-2H-21810

IMPELLER

29

04020-00820

PIN

30

708-2H-21830

GEAR

31

01010-51440

BOLT

32

01643-31445

WASHER

33

708-2H-21630

COVER

34

07000-A2105

O-RING

35

708-2H-05010

SHIM KIT

|$38

NSS

SHIM, 0.1 MM

|$39

NSS

SHIM, 0.2 MM

|$40

NSS

SHIM, 0.5 MM

36

01010-81235

BOLT

37

01643-31232

WASHER
