Запчасти Komatsu PW30T-1 ОСНОВНАЯ РАМА (ДЛЯ QUICK SHIFTER) (ДЛЯ ЯПОН.) СИСТЕМА УПРАВЛЕНИЯ¤ ОСНОВНАЯ РАМА И ШАССИ

1

21F-46-11252

FRAME,REVOLVING

|1

21F-46-11250

FRAME,REVOLVING

2

21E-46-11260

COVER

3

01220-40616

SCREW

4

01641-20608

WASHER

5

09463-00006

SPRING

6

04205-10618

PIN

7

04050-01610

PIN,COTTER

8

21E-46-11120

TUBE

8A

08036-11214

CLIP

8B

08036-10810

CLIP

8C

01010-50816

BOLT

8D

01602-20825

WASHER,SPRING

9

07831-00411

SLEEVE

10

07832-00410

NUT

11

20R-46-11160

CONNECTOR

11A

20R-46-11150

ELBOW

12

07020-00000

FITTING,GREASE

13

21E-46-11130

BRACKET

14

01010-51225

BOLT

15

01602-21236

WASHER,SPRING

16

08037-03614

GROMMET

17

21E-54-11341

BRACKET,(WITHOUT CAB)

|17

21E-54-11340

BRACKET,(WITHOUT CAB)

17A

21E-54-11710

BRACKET,(WITHOUT CAB¤ WITH L.H.MIRROR)

18

07049-01012

PLUG,(WITH CAB)

19

01010-50820

BOLT,(WITHOUT CAB)

|19

01010-50820

BOLT,(WITHOUT CAB)

20

01643-30823

WASHER,(WITHOUT CAB)

|20

01643-30823

WASHER,(WITHOUT CAB)

21

08174-13116

MIRROR,R.H.

21A

08174-13116

MIRROR,L.H.

22

20S-70-21440

SHAFT

23

01010-51235

BOLT

24

01602-21236

WASHER,SPRING

25

21E-70-11211

PIN

26

07020-00000

FITTING,GREASE

27

20S-70-21460

SPACER¤ 0.5MM

|27

20S-70-21470

SPACER¤ 1.0MM

28

01010-51630

BOLT

29

01643-31645

WASHER,SPRING

30

21E-70-11190

PIN

31

20S-70-21330

PIN

32

07020-00675

FITTING,GREASE

32A

07020-00000

FITTING,GREASE

33

01010-51225

BOLT

34

01602-21236

WASHER,SPRING

35

07049-01012

PLUG

36

21E-54-12120

COVER

37

01225-40310

SCREW
