Запчасти Komatsu PW30T-1 ГИДРОЛИНИЯ (ЦИЛИНДР ОТВАЛА ЛИНИЯ)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

07108-20311

HOSE

2

07108-20312

HOSE

3

21E-62-12220

ELBOW

4

07000-12014

O-RING

5

20R-62-22270

ELBOW

6

07002-12034

O-RING

7

202-981-1360

BUSHING

8

08034-00519

BAND

9

703-08-13111

SWIVEL JOINT ASS'Y,(SEE FIG.6151)

10

01010-51230

BOLT

11

01602-21236

WASHER,SPRING

12

20S-60-11210

PLATE

13

201-60-11230

PIN

14

04052-01664

PIN,SNAP

15

07108-20316

HOSE

16

20T-62-56710

UNION

17

20R-62-21131

ELBOW

18

07002-11823

O-RING

19

21E-63-02010

CYLINDER ASS'Y,BLADE (SEE FIG.7541)

20

203-62-41150

COVER

21

20B-62-32180

COVER

22

201-03-51320

SEAT

23

08034-00519

BAND

24

20S-62-11730

PLATE

25

01010-51020

BOLT

26

01602-21030

WASHER,SPRING

27

21F-914-1560

TUBE

28

21F-914-1570

TUBE

29

201-62-27750

COUPLING

30

201-62-27760

COUPLING

31

20T-914-4540

PLUG,DUST

32

20T-914-4550

PLUG,DUST

33

21F-914-1540

COVER

34

01010-50816

BOLT

35

01643-30823

WASHER
