Запчасти Komatsu PW30-1 ПАНЕЛЬ ПРИБОРОВ (ДЛЯ КАБИНЫ) (КРОМЕ ЯПОН.) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

1

20S-06-21270

PANEL

2

01220-40820

SCREW

3

01010-50820

BOLT

4

01602-20825

WASHER,SPRING

5

20S-06-21240

GAUGE ASS'Y,(SEE FIG.1413)

6

01224-70520

SCREW

7

08086-20000

SWITCH,STARTING

8

205-06-71331

SWITCH,LAMP

9

205-06-71650

KNOB

10

20S-06-21191

LIGHTER

11

09415-00706

CAP

12

09415-00706

CAP

13

09415-00706

CAP,(WITHOUT CAR HEATER)

13

205-06-71321

SWITCH,(FOR CAR HEATER AND DEFROSTER)

14

205-06-71341

SWITCH,WIPER

14

01641-21016

WASHER

15

20S-06-21210

ASHTRAY

16

20S-06-21130

BOX,FUSE

17

08040-02000

FUSE, 20A

18

150-06-14290

TERMINAL

19

20S-06-21150

PLATE

20

01220-40406

SCREW

21

01641-20405

WASHER

22

01220-40525

SCREW

23

01220-40520

SCREW

24

01580-10504

NUT

25

01641-20508

WASHER

26

21E-06-12110

COVER

27

20S-06-21170

PLATE

28

01220-40510

SCREW

29

362-54-23680

WASHER

30

21E-06-13222

WIRE ASS'Y

30

21E-06-13221

WIRE ASS'Y

30

21E-06-13220

WIRE ASS'Y

31

20S-06-21180

CLIP

32

08077-21201

FLASHER

33

01220-40408

SCREW

34

01641-20405

WASHER

35

20S-06-21380

WIRE

36

01010-50610

BOLT

37

01602-20619

WASHER,SPRING

38

08037-02512

GROMMET

39

08035-01510

CLIP
