Запчасти Komatsu PW220-7K СИДЕНЬЕ ОПЕРАТОРА В СБОРЕ¤ / (МЕХАНИЧ. ПОДВЕСКА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20K-57-31150

SEAT ASS'Y

1

20K-57-32120

SCREW

2

20K-57-31460

WASHER

3

20K-57-31420

NUT

4

20K-57-32220

COVER

5

20K-57-32230

SUSPENSION,UPPER

6

20K-57-32240

HANDLE

7

20K-57-32250

BELLOWS

8

20K-57-32260

RIVET

9

20K-57-32270

PLATE

10

20K-57-32280

BELT

11

20K-57-32290

BOLT

12

20K-57-32310

BUSHING

13

20K-57-32320

WASHER

14

20K-57-32330

ARM,SWING

15

20K-57-32340

BOLT

16

20K-57-32350

ROLLER

17

20K-57-32360

PLATE

18

20K-57-32370

SPRING

19

20K-57-32380

PLATE

20

20K-57-32390

BOLT

21

20K-57-32410

BOLT

22

20K-57-32420

SHOCK ABSORBER KIT

23

20K-57-32430

WASHER

24

20K-57-32440

FORK

25

20K-57-32450

RIVET

26

20K-57-32460

PLATE

27

20K-57-32470

PLATE,RUBBER

28

20K-57-32480

BUMPER SET

29

20K-57-32490

WASHER

30

20K-57-32510

WASHER KIT

31

20K-57-32520

SPRING

32

20K-57-32530

NUT

33

20K-57-32540

BRACKET

34

20K-57-32550

PLUG

35

20K-57-32560

SLEEVE,SPRING

36

20K-57-32570

PIN

37

20K-57-32580

YOKE

38

20K-57-32590

SHAFT

39

20K-57-32610

GUIDE

40

20K-57-32620

ROLLER

41

20K-57-32630

TAPE

42

20K-57-32640

SPRING

43

20K-57-32650

BUSHING

44

20K-57-32660

SUSPENSION,LOWER
