Запчасти Komatsu PW220-7K РУКОЯТЬ (.M) ( НАВЕСН.ОБОРУД. ЛИНИИ)(№K-K) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

07098-20612

HOSE

2

07000-13025

O-RING

3

07371-30640

FLANGE,SPLIT

4

07372-21035

BOLT

5

01643-51032

WASHER

6

20K-970-5330

TUBE

7

20K-62-32721

PLATE

8

20K-62-32711

CLAMP

9

01010-80855

BOLT

10

01643-30823

WASHER

11

20Y-970-K551

VALVE

12

07000-13025

O-RING

13

07371-30640

FLANGE,SPLIT

14

07372-21035

BOLT

15

01643-51032

WASHER

16

20K-970-5240

HOSE

17

07000-13032

O-RING

18

07371-31049

FLANGE,SPLIT

19

07372-21035

BOLT

20

01643-51032

WASHER

21

20K-62-41230

PLATE

22

20K-970-5180

TUBE

23

20K-62-41121

PLATE

24

20K-62-41111

CLAMP

25

01010-80875

BOLT

26

01643-30823

WASHER

27

20Y-970-K541

STOP VALVE

28

07000-13032

O-RING

29

07371-31049

FLANGE,SPLIT

30

07372-21035

BOLT

31

01643-51032

WASHER

32

20K-62-33950

PLATE

33

206-970-K560

PLATE

34

01010-81230

BOLT

35

01643-31232

WASHER

36

07378-10600

HEAD

37

07000-13025

O-RING

38

07371-30640

FLANGE,SPLIT

39

07372-21035

BOLT

40

01643-51032

WASHER

41

07378-11000

HEAD

42

07000-13032

O-RING

43

07371-31049

FLANGE,SPLIT

44

07372-21035

BOLT

45

01643-51032

WASHER

46

206-970-K550

BRACKET

47

01010-81630

BOLT

48

01643-31645

WASHER
