Запчасти Komatsu PW220-7H МОТОР ХОДА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PW220-7H - МОТОР ХОДА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
14
13
12
17
19
11
16
18
16
12
13
15
32
27
38
39
28
32
34
33
26
21
22
23
20
24
25
25
24
20
23
22
21
36
33
8
9
10
6
7
5
4
3
2
1
29
31
36
30
35
1
37
2
3
4
5
7
6
a
a

Артикул

Название

Примечание

Количество

|$1

20K-60-31111

MOTOR ASSEMBLY

|$3

20K-60-31850

END COVER SUB ASSEMBLY

|$4

20K-60-32370

VALVE ASSEMBLY

1

20K-60-32580

POPPET, VALVE

2

20K-60-32590

SPRING

3

20K-60-32610

SEAT

4

20K-60-32620

POPPET, VALVE

5

20K-60-32630

SPRING

6

20K-60-32640

SCREW

7

20K-60-32650

O-RING

|$12

20K-60-32380

SHUTTLE VALVE A.

8

20K-60-32660

SCREW, VALVE

9

20K-60-32670

BALL

10

20K-60-32680

BUSHING

|$16

20K-60-32390

PISTON ASSEMBLY, BRAKE

11

20K-60-32690

PISTON, BRAKE

12

20K-60-32710

BUSHING, VALVE

13

20K-60-32720

PIN, THROTTLE

14

20K-60-32730

SCREW, VALVE

15

20K-60-32740

BOLT

16

20K-60-32750

COLLAR

17

20K-60-32760

SCREW

18

20K-60-32770

SPRING

19

20K-60-32780

ORIFICE

|$26

20K-60-32410

CHECK VALVE ASSEMBLY

20

20K-60-32790

HOUSING,VALVE

21

20K-60-32810

HOUSING, VALVE

22

20K-60-32820

PISTON, VALVE

23

20K-60-32830

SPRING

24

20K-60-32840

O-RING

25

20K-60-32850

RING, BACK-UP

26

20K-60-32420

HOUSING

27

20K-60-32430

COVER

28

20K-60-32440

COVER

29

20K-60-32450

SCREW

30

20K-60-32460

SCREW

31

20K-60-32470

PLUG

32

20K-60-32480

O-RING

33

20G-60-K5020

O-RING

34

20K-60-32510

O-RING

35

20K-60-32520

SCREW

36

20K-60-32530

SCREW

37

20G-60-K2750

PIN

38

20K-60-32550

SCREW

39

20K-60-32560

SCREW

Выбрано товаров: 45
