Запчасти Komatsu PW220-7H ЦИЛИНДР ОТВАЛА Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20K-61-31111

CYLINDER ASSEMBLY

1

20K-61-31560

CYLINDER

2

20K-61-31550

ROD, PISTON

3

20K-61-31540

PISTON

4

20K-61-31530

GUIDE

5

20K-61-31520

SPOOL, CONTROL

6

20K-61-31510

SEAT, VALVE

7

20K-61-31490

SEAT, VALVE

8

20K-61-31480

POPPET, VALVE

9

20K-61-31470

BOLT

10

20K-61-31460

PLUG

11

20K-61-31450

PLUG

12

20K-61-31440

WIPER (KIT)

13

20K-61-31430

O-RING (KIT)

14

20K-61-31420

RING, WEAR (KIT)

15

20K-61-31410

O-RING (KIT)

16

20K-61-31390

RING, BACK-UP (KIT)

17

20K-61-31380

O-RING (KIT)

18

20K-61-31370

RING (KIT)

19

20K-61-31360

O-RING (KIT)

20

20K-61-31350

RING, BACK-UP (KIT)

21

20K-61-31340

RING, WEAR (KIT)

22

20K-61-31330

O-RING (KIT)

23

20K-61-31320

RING, BACK-UP (KIT)

24

20K-61-31310

O-RING (KIT)

25

20K-61-31290

RING, BACK-UP (KIT)

26

20K-61-31280

O-RING (KIT)

27

20K-61-31270

SPRING

28

20K-61-31260

SPRING

29

20K-61-31250

NUT, LOCK

30

20K-61-31240

SCREW

31

20K-61-31230

BEARING

32

20K-61-31220

NIPPLE, GREASE

KIT

20K-61-31210

SEAL KIT
