Запчасти Komatsu PW220-7E0 ЦИЛИНДР КОВША (БОЛЬШ.) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XT590

BUCKET CYLINDER, WITHOUT AUTO GREASE

G2

XXXX

BUCKET CYLINDER, WITH AUTO GREASE

|$2

707-01-0E080

CYLINDER ASSEMBLY

1

707-13-12500

CYLINDER

2

707-76-70110

BUSHING

3

07145-00070

SEAL (KIT)

4

707-58-85250

ROD

5

707-76-70120

BUSHING

6

20Y-70-23220

SEAL (KIT)

7

707-27-12960

HEAD

8

07179-13099

RING

9

707-56-85510

SEAL (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING (KIT)

12

07000-15115

O-RING (KIT)

13

707-35-91250

RING, BACK-UP (KIT)

14

707-51-85640

RING (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

721-36-12030

PISTON

18

707-35-90930

RING (KIT)

19

707-39-12560

RING (KIT)

20

707-44-12921

RING

21

707-35-90930

RING (KIT)

22

07000-15075

O-RING (KIT)

23

01310-01216

SCREW

24

01597-01009

NUT

25

01643-31032

WASHER

26

707-86-66280

TUBE

27

07372-21045

BOLT

28

07372-21060

BOLT

29

07000-13030

O-RING (KIT)

30

707-88-22780

BRACKET

31

707-88-21530

BAND

32

07372-21035

BOLT

33

07283-32738

CLIP

KIT

707-99-45230

SERVICE KIT
