Запчасти Komatsu PW220-7E0 ЦИЛИНДР СТРЕЛЫ(ДЛЯ ONE-ЧАСТИ СТРЕЛА) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XS950

CYLINDER LHS

G2

707-01-XS960

CYLINDER RHS

1

07372-21045

BOLT

2

07372-21060

BOLT

3

01643-51032

WASHER

4A

707-86-68320

TUBE LHS

4B

707-86-68330

TUBE RHS

5

07372-21035

BOLT

6

01643-51032

WASHER

7

707-88-21341

CLAMP

8A

707-88-25150

CLAMP LHS

8B

707-88-25100

CLAMP RHS

9

01643-31032

WASHER

10

01597-01009

NUT

11

07283-32738

CLIP

12

07000-13030

O-RING (KIT)

|$18

707-01-0H480

CYLINDER

13

707-76-80610

BUSHING

14

07145-00080

SEAL (KIT)

15

707-76-80590

BUSHING

16

707-41-11840

WASHER

17

01010-81875

BOLT

18

721-58-10050

ROD

19

07179-13114

RING

20

176-63-56170

SEAL (KIT)

21

707-27-14690

HEAD

22

707-51-10030

PACKING (KIT)

23

707-51-10650

RING (KIT)

24

707-35-91420

RING (KIT)

25

07000-15130

O-RING (KIT)

26

707-52-90780

BUSHING

27

707-75-10160

RING

28

707-35-91420

RING (KIT)

29

07000-15130

O-RING (KIT)

30

707-71-34880

COLLAR

31

CYLINDER

32

707-71-71020

PLUNGER

33

07001-05090

RING (KIT)

34

07000-15090

O-RING KIT)

35

707-44-14150

RING (KIT)

36

707-39-14110

RING (KIT)

37

707-44-14910

RING

38

707-36-14650

PISTON

39

01310-01216

SCREW

KIT

707-99-59220

SERVICE KIT
