Запчасти Komatsu PW220-7E0 ПЕРЕДНИЙ МОСТ (/) (.7M ШИР.) КОЛЕСА ВТУЛКА ASSEMBLY S ПОДВЕСКА И КОЛЕСА

Схема запчастей Komatsu PW220-7E0 - ПЕРЕДНИЙ МОСТ (/) (.7M ШИР.) КОЛЕСА ВТУЛКА ASSEMBLY S ПОДВЕСКА И КОЛЕСА
7
4
14
8
3
5
9
15
2
10
1
6
8
11
12
13
19
16
17
18
20
21
38
22
38
30
18
37
23
36
24
29
39
25
26
34
27
33
28
32
31
35
49
40
45
41
48
46
43
42
47
44

Артикул

Название

Примечание

Количество

|$1

20K-23-32001

AXLE ASSEMBLY

|$3

20J-22-11150

PLANETARY CARRIER ASSEMBLY

|$4

20J-22-11160

PLANETARY CARRIER

1

20K-23-31580

BUSHING

|$6

20G-23-H0P07

SEAL KIT

2

20G-23-31460

SEAL

3

20G-23-31470

RING

|$9

20K-23-31540

SHAFT ASSEMBLY

4

20J-23-11230

FORK

5

20J-23-11250

OUTER BODY

6

20J-23-11220

FORK

7

20K-23-32340

NIPPLE

8

20J-23-11240

SPIDER

9

20K-22-31340

FITTING

10

20K-22-31350

PLUG

11

20K-22-31360

PLUG

12

20K-23-31620

CIRCLIP

13

20K-23-31590

WASHER

14

20K-23-32260

SWIVEL HOUSING

15

20K-23-32250

SWIVEL HOUSING

16

20K-23-31570

RING

17

20K-22-31310

GASKET

18

20K-22-31370

BEARING

19

20K-22-31850

STUD

20

20G-23-H0P05

BOLT

21

20K-23-H0P02

HUB

22

20K-22-31440

O-RING

23

20J-22-11200

SHIM

24

20K-22-31420

SHIM, 0.5MM

25

20K-22-31410

SHIM, 0.3MM

26

20K-22-31260

BUSHING

27

20K-22-31250

WASHER

28

20K-22-31380

SCREW

|$35

20K-22-31290

BRAKE ASSEMBLY

29

20G-23-31910

PISTON

30

20J-23-11460

INNER BODY

31

20K-23-31880

WASHER, THRUST

32

20K-23-31890

DISC, OUTER

33

20K-23-32210

INNER DISC

34

20K-23-31920

SCREW

35

20K-23-31930

CIRCLIP

36

20K-23-32220

PISTON GASKET

37

20K-23-32230

PISTON GASKET

38

20K-23-32240

O-RING

39

20K-14-32610

SPRING

40

20K-22-31240

CIRCLIP

41

20K-22-31230

WHEEL

|$49

20J-22-11150

PLANETARY CARRIER ASSEMBLY

42

20J-22-11160

PLANETARY CARRIER

43

20K-22-31170

GEAR, SPUR

44

20K-22-31270

PLUG

45

20K-22-31180

WASHER

46

20K-22-31190

BEARING, ROLLER

47

20K-14-32330

PLUG

48

20G-23-31370

CLIP

49

20K-22-31280

PLUG

Выбрано товаров: 56
