Запчасти Komatsu PW220-7E0 ГИДР. БАК. (H - H9) H ГИДРАВЛИКА

1

01010-81635

BOLT

2

01011-81210

BOLT

3

01643-31232

WASHER

4

01643-31645

WASHER

5

02782-10315

ELBOW

6

02782-10424

ELBOW

7

02782-10425

ELBOW

8

02782-10522

ELBOW

9

02896-11009

O-RING

10

02896-11012

O-RING

11

02896-11015

O-RING

12

07000-13048

O-RING

13

07002-12034

O-RING

14

07002-12434

O-RING

15

07040-12012

PLUG

16

20K-54-33150

SHEET

17

20K-54-33160

SHEET

18

07002-12434

O-RING

19

07040-12412

PLUG

|$51

20K-60-33421

HYDRAULIC TANK ASSEMBLY

20

07285-00155

CLIP

21

07270-61513

TUBE

22

01601-20513

WASHER

23

01220-40512

SCREW

24

20Y-60-21340

GASKET

25

20Y-60-21460

FILLER NECK

26

17A-60-11310

CAP ASSEMBLY

|$50

20Y-60-21470

ELEMENT

27

01643-31232

WASHER

28

01010-81230

BOLT

29

07000-15160

O-RING

30

20K-60-32162

COVER

31

20Y-60-31140

STRAINER

32

07000-15195

O-RING

33

22U-60-21232

COVER

34

20Y-60-21240

SPRING

35

20Y-60-31131

VALVE ASSEMBLY

36

207-60-71182

ELEMENT

37

20Y-60-K1480

GAUGE

|$39

20Y-60-31171

STRAINER ASSEMBLY

38

22B-60-11160

STRAINER

|$41

207-60-61150

ROD ASSEMBLY

39

ROD

40

20Y-62-21320

HOLDER

41

12R-60-11230

SPRING

42

HYDRAULIC TANK

|$46

20K-62-31311

VALVE ASSEMBLY

43

20K-62-31141

BLOCK

44

20Y-62-27340

VALVE

45

20K-62-35670

TEE

46

20E-60-42150

FILTER ELEMENT

|$53

20E-60-42160

TANK CAP

47

20E-60-H0P04

BREATHER

48

20E-60-H0P00

PIN

49

BOLT

50

O-RING

51

FLANGE

52

20E-60-H0P07

SEAL
