Запчасти Komatsu PW210-1 ДОПОЛН. ГИДРОЛИНИЯ (CHAMGE ROTOR КРЕПЛЕНИЕ)(№-) ГИДРАВЛИКА

1

205-970-7341

BRACKET (WELDED)

2

205-970-7520

PLATE

3

01010-81240

BOLT

4

01643-31232

WASHER

5

205-970-7470

BLOCK

6

07040-12414

PLUG

7

07002-12434

O-RING

8

01010-81240

BOLT

9

01643-31232

WASHER

10

205-970-7341

BRACKET (WELDED)

11

205-970-7571

BRACKET

11

205-970-7570

PLATE

12

01010-81240

BOLT

13

01643-31232

WASHER

|$16

205-970-0010

ROTARY VALVE ASS'Y

14

205-970-7450

BLOCK

15

07040-12414

PLUG

16

07002-12434

O-RING

17

205-970-7460

ROTOR

18

07000-13042

O-RING

19

07001-03042

RING,BACK-UP

20

07000-13048

O-RING

21

07001-03048

RING,BACK-UP

22

04065-05220

RING,SNAP

23

202-970-2210

PIN

24

01010-81230

BOLT

25

01643-31232

WASHER

26

20K-970-1240

COVER

27

08036-40814

CLIP (WELDED)

28

205-970-7580

PLATE

28

205-970-7580

PLATE

29

205-970-7590

PLATE

30

205-970-5550

NIPPLE

31

07002-12434

O-RING

32

20Y-970-6450

ACCUMULATOR

32

205-970-5580

ACCUMULATOR

33

175-61-51750

PLATE

33

07283-31193

CLIP

34

01010-81225

BOLT

34

01599-01214

NUT

35

01643-31232

WASHER
