Запчасти Komatsu PW210-1 ОСНОВН. КЛАПАН (7/8) (ДЛЯ OFFSET СТРЕЛА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

709-79-12700

MAIN VALVE ASS'Y

|$3

709-75-93100

VALVE ASS'Y

1

BODY,VALVE

2

SPOOL

3

SPOOL

4

SPOOL

5

SPOOL

6

SPOOL

7

709-75-92110

PLATE

8

709-75-92120

SEAL

9

709-75-92130

RETAINER

10

709-75-92140

CASE

11

709-75-92150

SPRING

12

01252-60812

BOLT

13

01252-60820

BOLT

14

01252-60825

BOLT

15

01643-30823

WASHER

16

709-74-92170

O-RING

17

709-74-92110

RETAINER

18

709-74-92420

RETAINER

19

709-74-91990

RETAINER

20

709-74-91970

SLEEVE

21

04022-04008

PIN

22

709-74-92180

SPRING

23

709-74-92430

SPRING

24

709-74-92120

CASE

25

709-74-91980

CASE

26

709-74-92590

PLATE

27

709-74-91980

CASE

28

07040-11409

PLUG

29

07002-11423

O-RING

30

709-74-92210

SPRING

31

709-74-92230

PLUG

32

709-74-92260

PLATE

33

709-74-92270

WASHER

34

07002-13034

O-RING

35

07000-12018

O-RING

36

01252-60820

BOLT
