Запчасти Komatsu PW210-1 ОСНОВН. КЛАПАН (/8) (ДЛЯ OFFSET СТРЕЛА)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

709-79-12700

MAIN VALVE ASS'Y

|$3

709-74-92304

VALVE ASS'Y

1

BODY,VALVE

2

SPOOL

3

SPOOL

4

SPOOL

5

SPOOL

6

SPOOL

7

SPOOL

8

07000-11008

O-RING

9

07001-01008

RING,BACK-UP

10

709-74-92571

RETAINER

11

709-74-92680

SPRING

12

709-74-92690

SPRING

13

709-74-92540

CASE

14

01252-60820

BOLT

15

01252-60825

BOLT

16

01643-50823

WASHER

17

709-74-92170

O-RING

18

709-74-92110

RETAINER

19

709-74-91990

RETAINER

20

709-74-91970

SLEEVE

21

04022-04008

PIN

22

709-74-92180

SPRING

23

709-74-92360

SHIM, 0.5MM

24

709-74-92120

CASE

25

709-74-92140

CASE

26

709-74-91980

CASE

27

01252-60830

BOLT

28

01252-60820

BOLT

29

709-74-92561

PLUG

30

07000-12010

O-RING

31

700-23-13130

SPRING

32

709-74-92220

PLUG

33

709-74-92240

PLATE

34

709-74-92250

PLATE

35

709-74-92270

WASHER

36

07040-11409

PLUG

37

07002-11423

O-RING

38

07002-13034

O-RING

39

07000-12018

O-RING

40

01252-60820

BOLT
