Запчасти Komatsu PW210-1 ЦИЛИНДР СТРЕЛЫ(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

205-63-59300

BOOM CYLINDER ASS'Y,L.H.

|$1

205-63-59400

BOOM CYLINDER ASS'Y,R.H.

|$2

205-63-59310

CYLINDER SUB ASS'Y

1

205-63-59320

ROD,PISTON

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

07179-13099

RING,SNAP

5

707-56-85510

SEAL,DUST (KIT)

6

707-28-12561

HEAD,CYLINDER

7

01010-81665

BOLT

8

707-35-91220

RING,BACK-UP (KIT)

9

707-35-91230

RING,BACK-UP (KIT)

10

07000-15110

O-RING (KIT)

11

707-52-10850

BUSHING

12

707-51-85030

PACKING,ROD (KIT)

13

707-51-85630

RING,BUFFER (KIT)

14

707-71-50911

PLUNGER

15

707-44-12180

RING,PISTON (KIT)

15

707-44-12080

RING,PISTON

16

707-36-12330

PISTON

17

707-39-12110

RING,WEAR (KIT)

18

707-68-10580

NUT

19

205-63-52141

CYLINDER

20

707-76-70110

BUSHING

21

07145-00070

SEAL,DUST (KIT)

22

205-63-52170

TUBE,L.H.

22

205-63-52270

TUBE,R.H.

23

205-63-52180

TUBE,L.H.

23

205-63-52280

TUBE,R.H.

24

07000-13030

O-RING (KIT)

25

01010-50845

BOLT

26

01010-50855

BOLT

27

01602-20825

WASHER,SPRING

28

707-88-99230

BRACKET

29

707-88-99220

BAND

30

01010-51030

BOLT

31

01602-21030

WASHER,SPRING

32

07283-22738

CLIP

33

01599-01011

NUT

34

01643-31032

WASHER
