Запчасти Komatsu PW210-1 СТРЕЛА РАБОЧЕЕ ОБОРУДОВАНИЕ

|$1

205-70-00071

BOOM ASS'Y

|$2

205-70-00070

BOOM ASS'Y

1

BOOM

2

205-70-71291

BUSHING

2

205-70-71240

BUSHING

3

07020-00000

FITTING,GREASE

4

07145-00080

SEAL,DUST

5

07145-00080

SEAL,DUST

6

205-70-51450

SPACER, 1.0MM

7

205-70-61570

SPACER, 1.5MM

8

205-70-71160

PIN

9

205-70-71311

PLATE

10

01010-81640

BOLT

10

01010-51640

BOLT

11

01643-31645

WASHER

12

206-70-51190

PIN

12A

20Y-70-11390

SPACER, 0.8MM

12A

20Y-70-11370

SPACER, 1.5MM

13

205-70-65670

PLATE

14

205-70-73190

BOLT

15

01580-12016

NUT

16

205-70-65680

PIN

17

206-70-45220

SPACER, 1.0MM

17

206-70-45210

SPACER, 1.5MM

18

205-70-71310

PLATE

19

01010-81235

BOLT

19

01010-51235

BOLT

20

01643-31232

WASHER

21

205-70-71210

PIN

22

203-70-24170

SPACER, 1.0MM

23

205-70-66580

PLATE

24

01010-81235

BOLT

24

01010-51235

BOLT

25

01643-31232

WASHER

26

07020-00000

FITTING,GREASE

27

205-70-71320

PIN

28

205-70-51520

SPACER, 1.0MM

29

205-70-66580

PLATE

30

01010-81235

BOLT

30

01010-51235

BOLT

31

01643-31232

WASHER
