Запчасти Komatsu PW210-1 ПЕРЕДНИЙ МОСТ (КОЖУХ МОСТА) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$2

20K-22-10006

FRONT AXLE ASS'Y,(MODEL KWA03WS-2B)

|$3

20K-22-10005

FRONT AXLE ASS'Y

|$4

20K-22-10004

FRONT AXLE ASS'Y

|$5

20K-22-10002

FRONT AXLE ASS'Y

1

20K-22-13102

HOUSING,FRONT

1

20K-22-13101

HOUSING,FRONT

2

07044-12412

PLUG

3

07002-12434

O-RING

3

07002-02434

O-RING

4

176-76-67150

PLUG

4

07040-12414

PLUG

5

07002-02434

O-RING

6

20G-22-12570

BUSHING

7

20G-22-12590

SEAL,OIL

8

22X-23-23780

PLUG

9

22X-22-13450

BUSHING

10

22X-23-23470

WASHER

11

22X-23-23480

WASHER

12

22X-23-23790

SEAL

13

04020-01434

PIN,DOWEL

14

07030-01030

BREATHER

15

815-02-10110

PLATE, NAME,(LIMITED SUPPLY)

15

22X-22-13171

PLATE, NAME,(LIMITED SUPPLY)

16

04418-13060

SCREW

16

04418-03060

SCREW

17

20G-22-23160

BOLT,STOPPER

17

20G-22-23151

BOLT,STOPPER

18

20G-22-23250

SPACER, 23MM

18

20G-22-23260

SPACER, 26MM

18

20G-22-23220

SPACER, 29MM

18

20G-22-23230

SPACER, 32MM

18

01580-02016

NUT
