Запчасти Komatsu PW210-1 WRIST УПРАВЛ-Е И СТОЙКА¤ ЛЕВ. (/) (С INDEPENDENT L/R ЗАДН. ОПОРА¤F/R OR¤L/R И F/R OR) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20K-43-11111

STAND

2

20K-911-1260

COVER

3

205-43-71280

SCREW

4

205-43-73420

WASHER

5

20K-911-1280

BRACKET

6

205-43-71280

SCREW

7

205-43-73420

WASHER

8

20K-911-1270

COVER

9

205-43-71280

SCREW

10

205-43-73420

WASHER

11

205-43-72480

COVER

12

205-54-72240

ASHTRAY

13

01220-40408

SCREW

14

01601-20410

WASHER,SPRING

15

01642-20405

WASHER

16

20K-43-14220

LEVER,L.H.

16

205-43-71291

LEVER,L.H.

17

04025-00520

PIN,SPRING

18

04244-10633

ROD

19

04211-20634

YOKE

20

01580-10605

NUT

21

04205-10618

PIN

22

04050-11612

PIN,COTTER

23

20K-43-11240

LEVER

24

04010-00519

KEY,WOODRUFF

25

01010-80830

BOLT

25

01010-50830

BOLT

26

01602-20825

WASHER,SPRING

27

20K-43-11230

LEVER

28

195-61-34120

BEARING

29

01643-31645

WASHER

30

04050-14028

PIN,COTTER

31

01010-80820

BOLT

31

01010-50820

BOLT

32

01643-30823

WASHER

33

20G-00-11960

PLATE, OPERATING,(INDEPENDENT L/R OUTRIGGER)

34

20G-00-11970

PLATE, OPERATING,(INDEPENDENT F/R OUTRIGGER)
