Запчасти Komatsu PW200-7K ЦИЛИНДР РУКОЯТИ(С КЛАПАН БЕЗОПАСНОСТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX501

ARM CYLINDER GROUP, (FINAL COATING)

|1

707-01-0C421

CYLINDER ASSEMBLY

1

707-13-13540

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL, DUST (KIT)

4

707-58-95162

ROD, PISTON

5

707-27-13961

HEAD, CYLINDER

6

07179-13109

RING, SNAP

7

707-56-95510

SEAL, DUST (KIT)

8

707-52-90720

BUSHING

9

707-51-95030

PACKING, ROD (KIT)

10

07000-15125

O-RING (KIT)

11

707-35-91370

RING, BACK-UP (KIT)

12

707-51-95640

RING, BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-13771

PISTON

16

707-44-13280

RING, PISTON (KIT)

17

707-39-13530

RING, WEAR (KIT)

18

707-44-13920

RING

19

707-71-61070

PLUNGER

20

07000-15085

O-RING (KIT)

21

707-35-90960

RING, BACK-UP (KIT)

22

01310-01216

SCREW

23

707-71-70270

PLUNGER

24

07020-00000

FITTING, GREASE

25

707-71-32770

COLLAR

26

707-35-91370

RING, BACK-UP (KIT)

27

07000-15125

O-RING (KIT)

28

04260-00635

BALL

29

707-71-91270

CAP

30

707-83-13010

VALVE

31

07750-01628

SPRING

32

707-87-14070

PLUG

33

07002-12034

O-RING (KIT)

|K

707-99-57160

SERVICE KIT
