Запчасти Komatsu PW200-7K ПЕРЕДНИЙ МОСТ (/) (.7M ШИР.) S SUSPENTION И КОЛЕСА

|1

20K-23-32001

AXLE ASSEMBLY, FRONT

1

20K-23-31220

SHIM

2

20K-22-31620

SHIM

3

20K-23-31230

PLATE

4

20K-23-31240

SCREW

5

20K-23-31250

ROD, CONNECTING

|6

20K-23-31260

TIE ROD ASSEMBLY

6

20K-23-31270

TIE ROD

7

20K-23-31280

BEARING

8

20K-23-31290

NIPPLE

9

20K-23-31310

CAP, PROTECTION

10

20K-23-31320

COVER

11

20K-23-31330

BUSHING

12

20K-23-31340

HOSE, CYLINDER

13

20K-23-31350

FORK

14

20K-23-31360

PIN

15

20K-23-31370

GASKET, PISTON

16

20K-23-31380

RING, GROOVE

17

20K-23-31390

EXTRACTOR

18

20K-23-31410

O-RING

19

20K-23-31420

O-RING

20

20K-23-31430

SCREW

21

20K-23-31440

SCREW

22

20K-23-31450

PIN, SNAP

23

20K-23-31460

WASHER

24

20K-23-31470

WASHER

25

20K-23-31480

PLUG

26

20K-23-31490

O-RING

27

20K-23-31510

NUT

28

20K-23-31520

SCREW

29

20K-23-31530

GASKET, PISTON
