Запчасти Komatsu PW200-7K МЕХАНИЗМ ПОВОРОТА(№K-K) N ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7G-01040

MOTOR ASSEMBLY

2

22U-26-21280

RING

3

07042-00312

PLUG

4

22U-26-21190

CASE

5

07029-00000

VALVE

6

20Y-26-22330

BEARING

7

22U-26-21340

BEARING

8

20Y-26-31520

SHAFT, 12 TEETH

9

07012-00115

SEAL

10

22U-26-21270

SPACER

11

07000-15310

O-RING

12

22U-26-21580

CARRIER

13

22U-26-21540

GEAR

14

20G-26-11240

BEARING

15

20Y-27-21240

WASHER

16

20Y-26-22250

PIN

17

20Y-27-21280

PIN

18

20Y-26-21240

PLATE

19

112-32-11211

BOLT, SHOE

20

22U-26-21551

GEAR

|20

22U-26-21550

GEAR

21

20K-22-11190

O-RING

22

01010-81440

BOLT

23

01643-31445

WASHER

24

22U-26-21530

GEAR

25

22U-26-21570

CARRIER

26

22U-26-21520

GEAR

27

20Y-26-21281

BEARING

28

22U-26-21230

WASHER, THRUST

29

22U-26-21210

PIN

30

04064-03515

RING

31

22U-26-21250

WASHER, THRUST

32

22U-26-21510

GEAR

33

195-03-13241

VALVE

34

07270-21560

TUBE

35

07281-00197

CLAMP

36

01010-81035

BOLT

37

01643-51032

WASHER

38

20K-26-31140

TUBE

39

20K-26-31120

FILLER

40

20K-26-31130

GAUGE

41

20Y-26-31441

BRACKET

42

22U-26-21460

CAP

43

07238-10630

CONNECTOR

44

07283-32738

CLIP

45

04434-51710

CLIP

46

01597-01009

NUT

47

01643-31032

WASHER

48

01010-81030

BOLT

49

01643-31032

WASHER

50

01010-81025

BOLT

51

01643-31032

WASHER

52

07000-15240

O-RING

53

01010-82060

BOLT

54

01643-32060

WASHER

55

02782-10210

ELBOW

56

02896-11008

O-RING

57

07002-11423

O-RING

58

02782-10628

ELBOW

59

02896-11018

O-RING

60

07002-12434

O-RING

61

02782-10425

ELBOW

62

02896-11012

O-RING

63

07002-12434

O-RING
