Запчасти Komatsu PW200-7E0 ОСНОВН. КЛАПАН (8-СЕКЦИОНН.) (/) (ДЛЯ ONE-ЧАСТИ СТРЕЛА) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PW200-7E0 - ОСНОВН. КЛАПАН (8-СЕКЦИОНН.) (/) (ДЛЯ ONE-ЧАСТИ СТРЕЛА) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
3
9
8
7
8
5
6
4
6
1
10
16
15
14
15
12
13
11
17
23
22
21
22
19
20
18
20
1
24
30
29
28
29
26
27
25
27
1
31
37
36
35
36
33
34
32
34
1
38
44
43
42
43
40
41
39
45
51
50
49
50
47
48
46
48
1
52
58
57
56
57
54
55
53
55
2
A
A
A
A
B
B
B
C
C
C
D
D
E
E
F
F
G
G
H
H

Артикул

Название

Примечание

Количество

|$1

723-48-21201

VALVE ASSEMBLY

|$3

BODY SUB ASSEMBLY

1

723-46-41110

VALVE

2

723-46-41190

VALVE

|$7

723-46-40100

VALVE ASSEMBLY

3

SLEEVE

4

PISTON SUB ASSEMBLY

5

SPRING

6

SEAL

7

700-93-11320

O-RING

8

723-46-41950

RING

9

07002-13634

O-RING

|$15

723-46-42700

VALVE ASSEMBLY

10

SLEEVE

11

VALVE

12

SPRING

13

SEAL

14

700-93-11320

O-RING

15

723-46-41950

RING

16

07002-13634

O-RING

|$23

723-46-41100

VALVE ASSEMBLY

17

SLEEVE

18

PISTON SUB ASSEMBLY

19

SPRING

20

SEAL

21

700-93-11320

O-RING

22

723-46-41950

RING

23

07002-13634

O-RING

|$31

723-46-45100

VALVE ASSEMBLY

24

SLEEVE

25

PISTON SUB ASSEMBLY

26

SPRING

27

SEAL

28

700-93-11320

O-RING

29

723-46-41950

RING

30

07002-13634

O-RING

|$39

723-46-46300

VALVE ASSEMBLY

31

SLEEVE

32

PISTON SUB ASSEMBLY

33

SPRING

34

SEAL

35

700-93-11320

O-RING

36

723-46-41950

RING

37

07002-13634

O-RING

|$47

723-46-43400

VALVE ASSEMBLY

38

SLEEVE

39

VALVE SUB ASSEMBLY

40

SPRING

41

SEAL

42

700-93-11320

O-RING

43

723-46-41950

RING

44

07002-13634

O-RING

|$55

723-46-43100

VALVE ASSEMBLY

45

SLEEVE

46

PISTON SUB ASSEMBLY

47

SPRING

48

SEAL

49

700-93-11320

O-RING

50

723-46-41950

RING

51

07002-13634

O-RING

|$63

723-46-46101

VALVE ASSEMBLY

52

SLEEVE

53

PISTON SUB ASSEMBLY

54

SPRING

55

SEAL

56

700-93-11320

O-RING

57

723-46-41950

RING

58

07002-13634

O-RING

Выбрано товаров: 68
