Запчасти Komatsu PW200-7E0 МОТОР ХОДА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20K-60-31111

MOTOR ASSEMBLY

|$3

20K-60-31830

CONTROL ASSEMBLY

1

20E-60-K4520

HOUSING,CONTROL

2

20G-60-K2640

BUSHING, CONTROL

3

20K-20-32290

PISTON, CONTROL

4

20G-60-K4920

BUSHING, ADJUSTING

5

20K-60-32310

COLLAR

6

20K-60-32320

COLLAR

7

20G-60-K4290

SPRING

8

20K-60-32330

SPRING

9

20E-60-K4580

SPRING

10

20G-60-K4940

O-RING

11

20G-60-K4950

SCREW

12

20G-60-K4320

SCREW

13

20G-60-K2730

RING, RETAINING

14

20G-60-K1490

STUD

15

20G-60-K4960

PIN

16

20G-60-K1520

NUT, LOCK

17

20G-60-K2750

PIN

18

20G-60-K2590

PIN

19

20G-60-K2760

DISC, RETAINING

|$23

20K-60-31990

COVER ASSEMBLY

20

20E-60-K6680

COVER

21

20K-60-32340

SCREW

22

20E-60-K6690

SCREW

23

20G-60-K5020

O-RING

24

20G-60-K4320

SCREW
