Запчасти Komatsu PW200-7E0 МОТОР ПОВОРОТА (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

706-7G-01040

MOTOR ASSEMBLY

|$3

706-7G-03040

MOTOR SUB ASSEMBLY

1

706-7G-41610

SHAFT

2

706-75-42880

BEARING

3

706-75-43810

SPACER

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-76-40890

BEARING

7

706-75-05040

SPACER KIT

|$11

SPACER, 3.1MM

|$12

SPACER, 3.4MM

|$13

SPACER, 3.7MM

8

04064-04518

RING

9

706-7E-11280

SEAL

10

706-75-43720

SPACER

11

04065-06220

RING

12

706-7G-41210

BLOCK

13

706-7G-41710

PLATE

14

706-75-43750

PIN

15

706-7G-41120

SHAFT

16

706-7G-41130

RING

17

706-7G-41140

SPRING

|$24

706-7G-05010

RETAINER KIT

18

RETAINER

19

SCREW

20

706-7G-41160

PISTON SUB ASSEMBLY

21

706-7G-91340

PLATE

22

706-7G-91350

DISC

23

706-7G-91110

PISTON

24

706-77-40370

O-RING

25

708-8F-31610

O-RING

26

706-7G-91360

SPRING
