Запчасти Komatsu PW200-7E0 ЦИЛИНДР РУКОЯТИ(КЛАПАН БЕЗОПАСНОСТИ LESS) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XY821

ARM CYLINDER GROUP

1

01435-01040

BOLT

2

01435-01055

BOLT

3

707-86-66270

TUBE

4

07283-22738

CLIP

5

01599-01011

NUT

6

01643-31032

WASHER

7

707-88-11560

PLATE

8

01435-01075

BOLT

9

707-88-22530

BRACKET

10

707-88-21261

BAND

11

01435-01030

BOLT

12

07000-13030

O-RING (KIT)

13

07000-13035

O-RING (KIT)

14

20D-62-17860

ELBOW

|$16

707-01-0C421

CYLINDER ASSEMBLY

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-76-80010

BUSHING

18

07145-00080

SEAL (KIT)

19

07179-13109

RING

20

707-56-95510

SEAL (KIT)

21

707-27-13961

HEAD

22

707-51-95030

PACKING (KIT)

23

707-51-95640

RING (KIT)

24

707-35-91370

RING (KIT)

25

07000-15125

O-RING (KIT)

26

707-52-90720

BUSHING

27

707-35-91370

RING

28

07000-15125

O-RING

29

707-71-32770

COLLAR

30

707-58-95162

ROD

31

707-13-13540

CYLINDER

32

707-71-61070

PLUNGER

33

707-36-13771

PISTON

34

707-35-90960

RING (KIT)

35

07000-15085

O-RING (KIT)

36

04260-00635

BALL

37

707-71-91270

CAP

38

707-71-70270

PLUNGER

39

707-83-13010

VALVE

40

07750-01628

SPRING

41

07002-12034

O-RING (KIT)

42

707-87-14070

PLUG

43

707-44-13920

RING

44

707-39-13530

RING (KIT)

45

707-44-13280

RING (KIT)

46

01310-01216

SCREW

KIT

707-99-57160

SERVICE KIT
