Запчасти Komatsu PW200-7E0 ЦИЛИНДР СТРЕЛЫ(ДЛЯ ONE-ЧАСТИ СТРЕЛА) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XS280

CYLINDER LHS

G2

707-01-XS290

CYLINDER RHS

1

07372-21045

BOLT

2

07372-21060

BOLT

3

01643-51032

WASHER

4A

707-86-67520

TUBE LHS

4B

707-86-67530

TUBE RHS

5

07372-21035

BOLT

6

01643-51032

WASHER

7

707-88-21490

CLAMP

8A

707-88-25130

CLAMP LHS

8B

707-88-25140

CLAMP RHS

9

01643-31032

WASHER

10

01597-01009

NUT

11

07283-32738

CLIP

12

07000-13030

O-RING (KIT)

|$18

707-01-0H270

CYLINDER

13

707-76-80610

BUSHING

14

07145-00080

SEAL (KIT)

15

707-76-80590

BUSHING

16

707-41-11840

WASHER

17

01010-81875

BOLT

18

707-58-95250

ROD

19

07179-13109

RING

20

707-56-95510

SEAL (KIT)

21

707-27-13530

HEAD

22

707-51-95030

PACKING (KIT)

23

707-51-95650

RING (KIT)

24

707-35-91370

RING (KIT)

25

07000-15125

O-RING (KIT)

26

707-52-90720

BUSHING

27

707-75-95030

RING

28

707-35-91370

RING (KIT)

29

07000-15125

O-RING (KIT)

30

707-71-35010

COLLAR

31

CYLINDER

32

707-71-71010

PLUNGER

33

707-35-90960

RING (KIT)

34

07000-15085

O-RING KIT)

35

707-44-13250

RING (KIT)

36

707-39-13530

RING (KIT)

37

707-44-13920

RING

38

707-36-13771

PISTON

39

01310-01216

SCREW

KIT

707-99-50700

SERVICE KIT
