Запчасти Komatsu PW200-7E0 ЦИЛИНДР СТРЕЛЫ(ДЛЯ TWO-ЧАСТИ СТРЕЛА) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XS320

CYLINDER LHS

G2

707-01-XS330

CYLINDER RHS

1A

707-86-67660

TUBE LHS

1B

707-86-67680

TUBE RHS

2

01643-51032

WASHER

3

07372-21045

BOLT

4

07372-21060

BOLT

5

07000-13030

O-RING (KIT)

6

707-88-04370

CLIP

7

01643-31232

WASHER

8

01010-81230

BOLT

9

707-88-25660

CLAMP

10

01643-51032

WASHER

11

07372-21035

BOLT

12

707-88-21490

CLAMP

|$17

707-01-0H290

CYLINDER

13

707-76-10370

BUSHING

14

07145-00100

SEAL (KIT)

15

07145-00080

SEAL (KIT)

16

707-76-80410

BUSHING

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

07179-13109

RING

20

707-56-95510

SEAL (KIT)

21

707-27-13530

HEAD

22

707-51-95030

PACKING (KIT)

23

707-51-95650

RING (KIT)

24

707-35-91370

O-RING (KIT)

25

07000-15125

O-RING (KIT)

26

707-52-90720

BUSHING

27

707-75-95030

RING

28

707-35-91370

RING (KIT)

29

07000-15125

O-RING (KIT)

30

707-71-35010

COLLAR

31

CYLINDER

32

707-58-95260

ROD

33

707-71-71010

PLUNGER

34

707-35-90960

RING (KIT)

35

07000-15085

O-RING (KIT)

36

707-44-13250

RING (KIT)

37

707-39-13530

RING (KIT)

38

707-44-13920

RING

39

707-36-13771

PISTON

40

01310-01216

SCREW

KIT

707-99-50710

SERVICE KIT
