Запчасти Komatsu PW200-7E0 CENTRAL СМАЗКА (ФИДЕР ONE-ЧАСТИ-СТРЕЛА) W РАЗНОЕ

Схема запчастей Komatsu PW200-7E0 - CENTRAL СМАЗКА (ФИДЕР ONE-ЧАСТИ-СТРЕЛА) W РАЗНОЕ
9
11
11
12
10
21
20
22
17
9
15
14
1
13
17
11
2
7
8
15
12
16
18
9
6
5
19
15
4
3
1
1
2
19
4
6
5
12
5
2
1
6
4

Артикул

Название

Примечание

Количество

|$1

20K-S95-H160

PROGRESSIVE FEEDER

1

418-09-H0640

PLASTIC TUBE, 2.75M (MARK 1)

2

418-09-H0640

PLASTIC TUBE, 4.10M (MARK 5)

3

42W-09-H4280

COVER (SPIRAL)

4

418-09-H0640

PLASTIC TUBE, 4.10M (MARK 6)

5

42W-09-H4290

HOSE (MARK 3)

6

42W-09-H4300

HOSE (MARK 4)

7

42W-09-H3350

CAP

8

421-09-H3870

NIPPLE

9

418-09-H0640

PLASTIC TUBE, 2.00M (MARK 12)

10

42W-09-H4310

COVER (SPIRAL)

11

418-09-H0640

PLASTIC TUBE, 2.00M (MARK 11)

12

418-09-H0640

PLASTIC TUBE, 2.12M (MARK 14)

13

42W-09-H4320

MOUNTING PLATE

14

42W-09-H2980

FEEDER (WITH VALVES)

15

42W-09-H4650

VALVE

16

01010-80640

BOLT

17

42W-09-H2940

CAP

18

42W-09-H2880

UNION

19

42W-09-H4330

HOSE

20

01010-81270

BOLT

21

01643-31232

WASHER

22

421-03-31421

CUSHION

1

SWING CIRCLE

2

BOOM CYLINDER, BOTTOM, LHS

4

BOOM CYLINDER, BOTTOM, RHS

5

BOOM FOOT PIN, LHS

6

BOOM FOOT PIN, RHS

9

BOOM CYLINDER, TOP, LHS

11

BOOM CYLINDER, TOP, RHS

12

ARM CYLINDER, BOTTOM

Выбрано товаров: 31
