Запчасти Komatsu PW200-7E0 МЕХАНИЗМ ПОВОРОТА N ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$1

20K-26-31152

SWING MACHINERY

1

706-7G-01040

MOTOR ASSEMBLY

2

22U-26-21280

RING

3

07042-00312

PLUG

4

20Y-26-31110

CASE

5

20Y-26-22330

BEARING

6

20Y-26-22340

BEARING

7

20Y-26-31521

SHAFT

8

20Y-26-22420

SEAL

9

20Y-26-22191

COVER

10

01010-81045

BOLT

11

01643-31032

WASHER

12

07000-15310

O-RING

13

22U-26-21580

CARRIER

14

22U-26-21540

GEAR

15

20G-26-11240

BEARING

16

20Y-27-21240

WASHER

17

20Y-26-22250

PIN

18

20Y-27-21280

PIN

19

20Y-26-21240

PLATE

20

112-32-11211

BOLT, SHOE

21

22U-26-21551

GEAR

22

20K-22-11190

O-RING

23

01010-81440

BOLT

24

01643-31445

WASHER

25

22U-26-21530

GEAR

26

22U-26-21570

CARRIER

27

22U-26-21520

GEAR

28

20Y-26-21281

BEARING

29

22U-26-21230

WASHER

30

22U-26-21210

PIN

31

04064-03515

RING, SNAP

32

22U-26-21250

WASHER

33

22U-26-21510

GEAR

34

195-03-13241

VALVE

35

07270-21560

TUBE

36

07281-00197

CLAMP

37

01010-81035

BOLT

38

01643-51032

WASHER

39

20K-26-31140

TUBE

40

20K-26-31120

FILLER

41

20K-26-31130

GAUGE

42

20Y-26-31441

BRACKET

43

22U-26-21460

CAP

44

07238-10630

CONNECTOR

45

07283-32738

CLIP

46

04434-51710

CLIP

47

01597-01009

NUT

48

01643-31032

WASHER

49

01010-81030

BOLT

50

01643-31032

WASHER

51

01010-81025

BOLT

52

01643-31032

WASHER

53

07000-15240

O-RING

54

01010-82060

BOLT

55

01643-32060

WASHER

56

02782-10210

ELBOW

57

02896-11008

O-RING

58

07002-11423

O-RING

59

02782-10628

ELBOW

60

02896-11018

O-RING

61

07002-12434

O-RING

62

02782-10425

ELBOW

63

02896-11012

O-RING

64

07002-12434

O-RING
