Запчасти Komatsu PW200-7E0 ПОЛ (КОНСОЛЬН. БЛОК, RHS) K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-43-23110

STAY

2

20E-06-31561

WIRING HARNESS

3

22U-43-23120

BRACKET

4

22U-43-23130

STAY

5

20J-06-11630

SWITCH (QUICK COUPLER)

6

20J-43-12210

COVER

7

22U-06-22380

POTENTIOMETER

|$9

22U-06-22450

BRACKET

|$10

22U-06-22460

SPRING

8

22U-06-22470

KNOB

9

08086-20000

SWITCH

10

22U-06-22480

PLATE

11

22U-06-22290

SWITCH, SWING LOCK

12

20K-06-31750

SWITCH, PARK BRAKE

13

20J-06-11540

SWITCH (WORK LAMP)

14

20Y-06-23770

CLIP

15

20Y-06-23920

CLAMP

16

08034-10414

BAND

17

01023-60410

SCREW

18

01023-60512

SCREW

19

01023-10508

SCREW

20

01023-10512

SCREW

21

01601-20513

WASHER

22

01023-60620

SCREW

23

01023-70514

SCREW

24

22U-43-23210

COVER

25

08059-00310

CLIP

26

208-43-71420

CAP

27

20J-06-11110

PLATE

28

20J-06-11120

PLATE

29

20E-06-31151

HARNESS (PROLIX)

30

421-06-31121

SWITCH

31

22U-43-23230

COVER

32

20J-43-12231

FRAME

33

01023-60616

SCREW

34

569-06-61960

RELAY

35

287-06-16420

HOLDER

36

01435-00612

BOLT

37

01023-60416

SCREW

38

22U-43-23711

COVER

39

01023-10614

SCREW

40

01643-30623

WASHER

41

08034-20536

BAND

42

01010-D1030

BOLT

43

01643-71032

WASHER

44

20E-06-31161

PROLIX HARNESS
