Запчасти Komatsu PW200-7 ЦИЛИНДР КОВША Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XY831

BUCKET CYLINDER

G1

707-01-XY830

BUCKET CYLINDER

|$4

707-01-0C431

CYLINDER ASSEMBLY

|$5

707-01-0C430

CYLINDER ASSEMBLY

1

707-13-11561

CYLINDER

|$7

707-13-11560

CYLINDER

2

707-76-70110

BUSHING

3

07145-00070

SEAL, DUST (KIT)

4

707-58-80651

ROD, PISTON

5

707-76-70120

BUSHING

6

20Y-70-23220

SEAL, DUST (KIT)

7

707-27-11870

HEAD

|$14

707-27-11981

HEAD, CYLINDER

8

07179-13094

RING, SNAP

9

195-63-92190

SEAL, DUST (KIT)

10A

707-52-90560

BUSHING

10B

707-75-80040

RING

11

707-51-80030

PACKING, ROD (KIT)

12

07000-15105

O-RING (KIT)

13

707-35-91150

RING, BACK-UP (KIT)

14

707-51-80640

RING, BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-11851

PISTON

18

707-44-11280

RING, PISTON (KIT)

19

707-39-11530

RING, WEAR (KIT)

20

707-44-11920

RING

21

707-35-90360

RING (KIT)

22

07000-15070

O-RING (KIT)

23

01310-01216

SCREW

24

707-86-66281

TUBE

|$33

707-86-66280

TUBE

25

07372-21060

BOLT

|$35

01643-51032

WASHER

|$36

01435-01055

BOLT, WITH WASHER

26

07372-21045

BOLT

|$38

01643-51032

WASHER

|$39

01435-01040

BOLT, WITH WASHER

27

07000-13030

O-RING (KIT)

28

707-88-22570

BRACKET

29

707-88-21271

BAND

30

07372-21035

BOLT

|$44

01643-51032

WASHER

|$45

01435-01030

BOLT, WITH WASHER

31

07283-22738

CLIP

32

01599-01011

NUT

33

01643-31032

WASHER

KIT

707-99-45230

SERVICE KIT
