Запчасти Komatsu PW200-1 МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-87-01103

MOTOR ASS'Y

|1

706-87-01102

MOTOR ASS'Y

|1

702-66-01100

BRAKE VALVE ASS'Y

1

BODY,VALVE

2

07043-70211

PLUG

3

07040-11007

PLUG

4

07002-01023

O-RING

5

706-77-72170

PLUG

6

07002-12434

O-RING

7

SPOOL

8

706-76-71350

VALVE

9

700-42-31210

SPRING

10

706-76-71430

PLUG

11

07002-12434

O-RING

12

706-76-71411

RETAINER

13

706-76-71420

SPRING

|14

702-66-00010

COVER SUB ASS'Y

14

COVER

15

SCREW

16

702-66-11120

COVER

17

702-66-11140

PIN

18

706-73-71450

PLUG

19

07002-11423

O-RING

20

07000-12010

O-RING

21

706-76-71390

O-RING

22

720-68-11510

BOLT

|23

702-76-01100

VALVE ASS'Y

23

SLEEVE

24

07000-23022

O-RING

25

07001-03022

RING,BACK-UP

26

700-93-11320

O-RING

27

700-93-11330

RING,BACK-UP

28

07002-03634

O-RING

29

RING,SNAP

30

VALVE

31

SPRING

32

SEAT

33

O-RING

34

RING,BACK-UP

35

POPPET

36

RETAINER

37

SPRING

38

SLEEVE

39

PLUG

40

NUT

41

O-RING
