Запчасти Komatsu PW200-1 ЗАДН. МОСТ (КОНЕЧНАЯ ПЕРЕДАЧА) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

20K-22-19004

REAR AXLE ASS'Y

|1

20K-22-19003

REAR AXLE ASS'Y

|1

20K-22-19001

REAR AXLE ASS'Y

1

20G-32-21911

DISC

|1

20G-32-21910

DISC

2

20G-32-21950

BOLT,12POINT

3

20G-22-22710

HUB

|4

20G-22-12320

BEARING

4

20G-22-12330

CONE,BEARING

5

20G-22-12340

CUP,BEARING

6

20K-22-12750

SEAL,OIL

|6

20G-22-12750

SEAL,OIL

7

20G-22-22791

RING

|7

20G-22-22790

RING

8

20G-22-22140

BOLT

9

20G-22-22130

PLATE,LOCK

|10

20G-22-22350

BEARING

10

20G-22-22360

CONE,BEARING

11

20G-22-22370

CUP,BEARING

12

20G-22-22310

HUB,RING GEAR

13

20G-22-22110

GEAR,RING

14

20G-22-12440

SHIM¤ 0.10MM

|14

20G-22-12450

SHIM¤ 0.15MM

|14

20G-22-12460

SHIM¤ 0.20MM

|14

20G-22-12470

SHIM¤ 0.50MM

|14

20G-22-12470

SHIM¤ 0.50MM

15

20G-22-12431

RETAINER

16

01252-31045

BOLT

17

20G-22-22420

GEAR,SUN

18

04064-04018

RING,SNAP

19

20G-22-22612

CARRIER

|19

20G-22-22611

CARRIER

20

130-09-14330

BEARING

21

20G-22-22210

GEAR,PLANETARY

22

20G-22-22270

WASHER

23

20G-22-12260

WASHER

24

20G-22-22651

SHAFT

25

07000-03045

O-RING

26

04025-00820

PIN

27

20G-22-12630

BUTTON,THRUST

28

20G-22-12680

O-RING

29

07000-02012

O-RING

30

01010-61235

BOLT

|30

01010-31235

BOLT

31

20G-22-22720

BOLT

32

20G-22-12870

NUT

33

20G-22-12880

COLLAR

34

20G-22-12860

WASHER,SPRING

35

176-76-67150

PLUG

|35

07040-12414

PLUG

36

07002-12434

O-RING

|36

07002-02434

O-RING

37

07040-11007

PLUG

38

07002-01023

O-RING

39

20G-32-21930

BOLT,12POINT¤ REAR AXLE
