Запчасти Komatsu PW180-7K ЦИЛИНДР СТРЕЛЫ(ДЛЯ 1-СЕКЦИОНН. СТРЕЛЫ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS110

CYLINDER ASSEMBLY,L.H. (FINAL COATING)

G-2

707-01-XS120

CYLINDER ASSEMBLY,R.H. (FINAL COATING)

|1

707-01-0H320

CYLINDER ASSEMBLY

1

707-13-12550

CYLINDER

2

21K-70-71320

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-85420

ROD,PISTON

6

707-76-80230

BUSHING

7

07145-00080

SEAL,DUST (KIT)

8

707-27-12420

HEAD,CYLINDER

9

07179-13099

RING,SNAP

10

707-56-85510

SEAL,DUST (KIT)

11

707-52-90610

BUSHING

12

707-51-85030

PACKING,ROD (KIT)

13

07000-15110

O-RING (KIT)

14

707-35-91220

RING,BACK-UP (KIT)

15

707-51-85640

RING,BUFFER (KIT)

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-12851

PISTON

19

707-44-12180

RING,PISTON (KIT)

20

707-39-12140

RING,WEAR (KIT)

21

707-44-12911

RING

22

707-71-70820

PLUNGER

23

07000-15075

O-RING (KIT)

24

707-35-90930

RING,BACK-UP (KIT)

25

01310-01216

SCREW

26

707-71-34890

COLLAR

27

707-35-91220

RING,BACK-UP (KIT)

28

07000-15110

O-RING (KIT)

29

707-86-48130

TUBE,L.H.

|29

707-86-48140

TUBE,R.H.

30

01010-80845

BOLT

31

01643-50823

WASHER

32

07000-13025

O-RING (KIT)

33

707-88-25990

BRACKET,L.H.

|33

707-88-25500

BRACKET,R.H.

34

707-88-21251

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

07283-32236

CLIP

38

01597-01009

NUT

39

01643-31032

WASHER

40

02896-11015

O-RING (KIT)

41

707-88-33030

HEAD

42

07371-30640

FLANGE

43

07372-21035

BOLT

44

01643-31032

WASHER

|K

707-99-46330

SERVICE KIT
